    24VDC Pneumatic Double Solenoid Valve 4V220-08 Good Corrosion Resistance

    Ask Lasest Price
    Brand Name : DOPOW
    Model Number : 4V220-08
    Certification : CE ISO9001
    Price : Negotiable
    Payment Terms : L/C, D/P, T/T, Western Union
    Supply Ability : 100000PCS/MO
    Delivery Time : 5 working days after receiving the customers' payment
    • Product Details
    • Company Profile

    24VDC Pneumatic Double Solenoid Valve 4V220-08 Good Corrosion Resistance

    24VDC Pneumatic Double Solenoid Valve 4V220-08


    1. The strength of the aluminum alloy valve body is large. The valve body is made of new aluminum alloy material, which has strong pressure resistance,good corrosion resistance and fast heat dissipation;
    2. High quality sealing ring. High quality seals for durability and longer life;
    3. High precision valve stem. Imported high-quality lubricants to ensure lubrication and reduce friction during exercise;
    4. High frequency sub-head. Made of high-quality conductor material with 5 times in 1 second high intensity and high frequency response for smoother operation;
    5. The coil is easy to disassemble. Removable core nut, coil can be replaced at any time;
    6. High quality electronic components. The copper coil can work hard for a long time, the wiring operation is simple;
    7. Used for controlling pilots or diaphragms of larger valves or small cylinders or any pressure system that is alternatively pressurized and exhausted.

    4V220-08 Airtac Type Pneumatic Solenoid Valve 4V220-08-DC24V DC24V 0

    Model4V210-064V220-064V230C-064V230E-064V230P-064V210-084V220-084V230C-084V230E-084V230P-08
    4A210-064A220-064A230C-064A230E-064A230P-064A210-084A220-084A230C-084A230E-084A230P-08
    Valve type5/2 way5/3 way5/2 way5/3 way
    Effectiive area14 mm2(CV=0.78)12 mm2(CV=0.67)16 mm2(CV=0.89)12 mm2(CV=0.67)
    Model3V210-063V220-063A210-063A220-063V210-083V220-083A210-083A220-08
    Valve type3/2 way
    Effective area14 mm2(CV=0.78)16 mm2(CV=0.89)
    Port sizeInlet , outlet,exhaust port=1/8"Inlet, outlet=1/4", Exhaust port=1/8"
    Working medium40 micron filtered air
    OperationInternal piloted
    Working pressure0.15-0.8 Mpa
    Max. pressure1.2 Mpa
    Temperature5-50 degrees centigrade
    Voltage tolerancePlus or minus 10%
    Power consumptionAC:5.5 VA, DC:4.8W
    Connector protectionF Class , IP65
    Wiring/ConnectorCable/Lead wire or DIN connector
    Frequency5 cycles/ sec
    Response time0.05 sec

    Quality 24VDC Pneumatic Double Solenoid Valve 4V220-08 Good Corrosion Resistance for sale
