    5 Way 2 Position Pneumatic Solenoid Valve Direct Acting 4V310-10

    Ask Lasest Price
    Brand Name : DOPOW
    Model Number : 4V310-10
    Certification : CE ISO9001
    Price : Negotiable
    Payment Terms : L/C, D/P, T/T, Western Union
    Supply Ability : 100000PCS/MO
    Delivery Time : 5 working days after receiving the customers' payment
    • Product Details
    • Company Profile

    5 Way 2 Position Pneumatic Solenoid Valve Direct Acting 4V310-10

    4V Series Airtac Type Pneumatic 5/2 Port Control Solenoid Valve 4V310-10


    Pneumatic solenoid valves can be found in a wide range of industries. They are used in Pneumatic Artificial Muscles (PAM) for robotics and automation. Manufacturing companies that use conveyors belts uses pneumatic valves in their conveyor belt systems. Food and beverage manufacturers use them to make, dispense or preserve food and beverage products.


    This 4V310-10 solenoid valve is the 3/8'' 5 way 2 Position Pneumatic Solenoid Valve. It is a switch for routing air to any pneumatic device, usually an actuator, allowing a relatively small signal to control a large device. It is also the interface between electronic controllers and pneumatic systems. This valve allows pneumatic control of position, flow, pressure and temperature.


    Data of 4V300 Series Pneumatic Solenoid Valves:

    Model
    4V310-08
    4V320-08
    4V330C-08
    4V330E-08
    4V330P-08
    4V310-10
    4V320-10
    4V330C-10
    4V330E-10
    4V330P-10
    Fluid
    Air(to be filtered by 40 μ m filter element)
    Acting
    Internal pilot or external pilot
    Port Size
    In=Out=Exhaust=1/4''
    In=Out=3/8'' Exhaust=1/4''
    Orifice Size
    25.00 mm2(Cv=1.40)
    18.00 mm2(Cv=1.00)
    30.00 mm2(Cv=1.68)
    18.00 mm2(Cv=1.00)
    Valve Type
    5 port 2 position
    5 port 3 position
    5 port 2 position
    5 port 3 position
    Operating Pressure
    0.15~0.8MPa(21~114psi)
    Proof Pressure
    1.5MPa(215psi)
    Temperature ℃
    -20~70
    Material of Body
    Aluminum alloy
    Max. frequency
    4 cycle/sec
    4 cycle/sec
    4 cycle/sec
    4 cycle/sec


    Dimension of 4V310-10 Pneumatic Solenoid Valve:

    4V310-10 Airtac Type Solenoid Valve 4V310-10-DC24V 4V310-10-AC220V 0
